SPECIFICATIONS
- 7075-T9 aerospace alloy
- Hard-anodized finish
- Guaranteed straightness: ± .002″
- Weight tolerance: ± 1%
- Strength (psi): 96,000
- Super or G UNI bushings—installed
- Components—sold separately
-
Sizes: 1416, 1516, 1616, 1713, 1716, 1813, 1816, 1913, 1916, 2013, 2016, 2114, 2213, 2315
| SIZE | SHAFT WEIGHT GPI |
SPINE @ 28″ SPAN DEFLECTION IN INCHES |
SHAFT O.D. INCHES |
STOCK LENGTH INCHES |
|---|---|---|---|---|
| 1416 | 7.4 | 1.684 | 0.219 | 27.5 |
| 1516 | 7.3 | 1.403 | 0.234 | 28 |
| 1616 | 8.4 | 1.079 | 0.250 | 29 |
| 1713 | 7.4 | 1.044 | 0.266 | 29 |
| 1716 | 9.0 | 0.880 | 0.266 | 29 |
| 1813 | 7.9 | 0.874 | 0.282 | 30 |
| 1816 | 9.3 | 0.756 | 0.281 | 30 |
| 1913 | 8.3 | 0.733 | 0.298 | 31.5 |
| 1916 | 10.0 | 0.623 | 0.297 | 31 |
| 2013 | 9.0 | 0.610 | 0.313 | 32.5 |
| 2016 | 10.6 | 0.531 | 0.312 | 32 |
| 2114 | 9.9 | 0.507 | 0.328 | 31 |
| 2213 | 9.8 | 0.458 | 0.344 | 31.5 |
| 2315 | 11.7 | 0.342 | 0.365 | 32.5 |
